Buy the AJ717A – HPE Storage Transceivers at the Best Price in Bangladesh
AJ717A – HPE Storage Transceivers is a top-tier Fibre Channel SFP+ transceiver designed to meet the demands of modern data storage and networking environments. With an 8 Gbps data rate and a long-range capability of up to 10 km, this transceiver ensures fast, reliable data transmission across extended distances. It operates at a wavelength of 1310 nm and is compatible with M-Series Fibre Channel Switches, making it a versatile choice for enterprise networks. Additionally, its robust design and compliance with industry standards like RoHS, CE, and FCC ensure reliability and safety in various applications.
Key Features:
- 8 Gbps data transfer rate
- Supports distances up to 10 km
- 1310 nm wavelength for long-range communication
- Compatible with M-Series Fibre Channel Switches
- Low power consumption at 3.5W
- Digital Diagnostic Monitoring (DDM) for real-time performance tracking
- RoHS, CE, and FCC compliant
- Class 1 laser safety
User Experience
Users of the AJ717A – HPE Storage Transceivers will appreciate its ease of installation, reliable performance, and energy efficiency. The transceiver’s compatibility with M-Series Fibre Channel Switches ensures seamless integration into existing networks, reducing the time and effort required for deployment. The inclusion of Digital Diagnostic Monitoring enhances the user experience by providing real-time insights into the transceiver’s performance, enabling proactive network management.
Why Choose AJ717A – HPE Storage Transceivers?
Choosing the AJ717A – HPE Storage Transceivers means investing in a reliable, high-performance networking solution that supports long-distance data transmission. Its 8 Gbps data rate, combined with the ability to transmit data over distances of up to 10 km, makes it an ideal choice for businesses with extensive networking needs. The transceiver’s energy efficiency, real-time performance monitoring, and robust safety features further reinforce its value as a dependable component in any enterprise network.
Product Specifications
Specification | Details |
---|---|
Brand | HPE |
Model | AJ717A |
Type | Fibre Channel SFP+ Transceiver |
Data Rate | 8 Gbps |
Distance | 10 km |
Wavelength | 1310 nm |
Form Factor | SFP+ |
Pack Size | 1 Pack |
Product Type | Transceiver Module |
Compatibility | M-Series Fibre Channel Switches |
Optical Connector | LC Connector |
Power Consumption | 3.5W |
Operating Temperature Range | -20°C to 85°C |
Storage Temperature Range | -40°C to 85°C |
MTBF | 1,000,000 hours |
Compliance | RoHS, CE, FCC |
Digital Diagnostic Monitoring | Yes |
Signal Conversion | Yes |
Receiver Sensitivity | -12 dBm |
Transmit Power | -8 dBm to 0 dBm |
Laser Class | Class 1 |
Dimensions | 57 mm x 14 mm x 13 mm |
Installation Steps
- Prepare the Device: Ensure that the network device is powered down before installation.
- Insert the Transceiver: Gently insert the AJ717A – HP Storage Transceivers into the SFP+ port of the compatible M-Series Fibre Channel Switch.
- Connect the Fiber Cable: Attach the LC connector fiber cable to the transceiver.
- Power On the Device: Once the transceiver is securely connected, power on the device.
- Verify Functionality: Use network monitoring tools to confirm that the transceiver is operating correctly and to monitor its performance via Digital Diagnostic Monitoring.
Uses of the AJ717A – HPE Storage Transceivers
The AJ717A – HP Storage Transceivers is ideal for long-distance data communication in enterprise networks, data centers, and other high-demand environments. Designed for use with M-Series Fibre Channel Switches, it’s perfect for large-scale deployments requiring reliable, high-speed data transmission over extended distances.
What is the Price of AJ717A – HPE Storage Transceivers in BD?
Discover a wide range of accessories and storage at unbeatable prices in Bangladesh with Crystal Vision Solutions. We offer all-branded Storage Transceivers, including AJ717A – HPE Storage Transceivers at the best prices in BD. To know the current price of this product please call us or visit our shop.
FAQs
1. What is the maximum distance supported by the AJ717A?
Ans: The AJ717A – HP Storage Transceivers supports a maximum distance of 10 km.
2. Is the AJ717A compatible with all HP switches?
Ans: This transceiver is specifically designed for compatibility with M-Series Fibre Channel Switches.
3. How do I install the AJ717A?
Ans: Installation is simple: insert the transceiver into an SFP+ port, connect the fiber cable, and power on the device.
4. What is the data transfer rate of the AJ717A?
Ans: The AJ717A – HPE Storage Transceivers offers a data transfer rate of 8 Gbps.
5. Does the AJ717A support Digital Diagnostic Monitoring?
Ans: Yes, the AJ717A – HPE Storage Transceivers supports Digital Diagnostic Monitoring for real-time performance tracking.
