About the Juniper EX2300-24MP Switch
The Juniper EX2300-24MP Switch is a high-performance, versatile networking solution designed to meet the needs of modern enterprises. With a fixed 1U form factor, it offers robust connectivity options, including a mix of 100M/1/2.5GbE and 1GbE ports, along with SFP/SFP+ 10GbE uplinks. Its advanced features such as Virtual Chassis technology and cloud management provide scalability and easy network administration. The EX2300-24MP Switch combines high data rates and throughput with reliable performance, making it an excellent choice for both small and medium-sized business environments.
Specification
EATURES | Details |
---|---|
Type | Switch |
Form Factor | Fixed 1 U access |
Port Density | 8 x 100M/1/2.5GbE, 16 x 1GbE, 4 SFP/SFP+ 10GbE |
Wired Assurance | Yes |
Campus Fabrics | Virtual Chassis |
Cloud Managed | Yes |
Dimensions (W x H x D) | 17.4 x 1.75 x 10.0 in. (44.19 x 4.45 x 25.4 cm) |
Backplane Speed | 80 Gbps Virtual Chassis interconnect |
Data Rate | 208 Gbps |
Throughput | 154 Mpps |
Resiliency | Integrated power supply and fans |
Traffic Monitoring | sFlow |
Quality-of-Service (QoS) Queues/Port | 8 |
MAC Addresses | 16,000 |
Jumbo Frames | 9216 bytes |
IPv4 Unicast/Multicast Routes | 4096 / 4096 |
IPv6 Unicast/Multicast Routes | 2048 / 2048 |
Number of VLANs | 4093 |
ARP Entries | 5000 |
Description
The Juniper EX2300-24MP Switch offers impressive performance and versatility in a compact 1U design. It features 8 ports of 100M/1/2.5GbE, 16 ports of 1GbE, and 4 SFP/SFP+ 10GbE uplinks, delivering high-speed connectivity for diverse networking needs. The switch’s high data rate of 208 Gbps and throughput of 154 Mpps ensure efficient data handling. With Virtual Chassis technology, it can link up to four switches as a single logical device, enhancing scalability. Cloud management and sFlow monitoring simplify network administration, while integrated power supplies and fans provide reliability.
User Experience
Users find the Juniper EX2300-24MP Switch to be highly reliable and easy to manage. Its 1U form factor is well-suited for rack-mounted setups, while its high data rate and throughput support demanding network environments. The switch’s PoE capabilities and Virtual Chassis technology facilitate flexible deployment and expansion. Cloud management tools offer intuitive configuration and monitoring, enhancing overall usability. Customers appreciate its robust performance, advanced features, and reliability, making the EX2300-24MP an excellent choice for businesses seeking a powerful and scalable networking solution.
Why Choose the Juniper EX2300-24MP Switch?
The Juniper EX2300-24MP Switch stands out for its combination of high performance and compact design. It offers 8 x 100M/1/2.5GbE ports, 16 x 1GbE ports, and 4 SFP/SFP+ 10GbE uplinks, making it versatile for various networking needs. Its high data rate of 208 Gbps and 154 Mpps throughput ensure efficient data processing. Virtual Chassis technology allows for easy scaling, while cloud management simplifies administration. With integrated resiliency features and advanced traffic monitoring, the EX2300-24MP provides a reliable and flexible solution for modern network infrastructures.
What is the Price of Juniper EX2300-24MP Network Switch in Bangladesh?
Crystal Vision Solutions specializes in networking equipment solutions, including the Juniper EX2300-24MP Network Switch, catering to diverse needs in Bangladesh. Our products ensure optimal performance and reliability, backed by competitive pricing and expert service to meet your business’s requirements effectively.
