Swissbit M.2 PCIe SSD N2600 M2 Series 20GB is designed to deliver high-speed data access and reliable performance in a compact form factor. This SSD is ideal for industrial applications, embedded systems, and other environments that demand robust and efficient storage solutions.
Key Features:
- Capacity: 20GB
- Read Performance: Up to 1,780 MBytes/s
- Write Performance: Up to 867 MBytes/s
- Operating Temperature Range: -40 °C to 85 °C
- Shock/Vibration Resistance: 1,500 g / 50 g
- Data Reliability: < 1 non-recoverable error per 10¹⁶ bits read
Detailed Breakdown of Features
Performance
- Read Performance: With sequential read speeds up to 1,780 MBytes/s and random read 4K up to 89,000 IOPS, the Swissbit M.2 PCIe SSD N2600 M2 Series 20GB ensures rapid data access.
- Write Performance: Sequential write speeds up to 867 MBytes/s and random write 4K up to 136,000 IOPS make data storage quick and efficient.
Durability
- Operating Temperature Range: Designed to operate in temperatures ranging from -40 °C to 85 °C, it is perfect for harsh industrial environments.
- Shock/Vibration: Built to withstand 1,500 g of shock and 50 g of vibration, ensuring durability in rugged conditions.
Power Efficiency
- Operating Voltage: Supports 3.3V, 1.8V, and 0.9V supply voltages for flexible power options.
- Low Power Consumption: Includes multiple power states (PS0, PS1, PS2, PS3, and PS4) and thermal throttling to manage power use efficiently.
Data Reliability and Endurance
- NAND Flash Technology: Utilizes Triple-Level Cell (TLC) 3D NAND Flash in pSLC mode for enhanced performance and reliability.
- Endurance (TBW): Client endurance is rated ≥ 6,300 TBW at 80GB capacity.
- Mean Time Between Failure (MTBF): > 2,000,000 hours for long-lasting reliability.
User Experience
Users of the Swissbit M.2 PCIe SSD N2600 M2 Series 20GB can expect a seamless and efficient storage experience. The SSD’s high-speed performance, coupled with its robust construction, ensures reliable data access and storage even in demanding environments. Features like Host Memory Buffer (HMB) support and low power consumption enhance overall user satisfaction.
Why Choose Swissbit M.2 PCIe SSD N2600 M2 Series 20 GB?
Choosing the Swissbit M.2 PCIe SSD N2600 M2 Series 20GB means opting for a high-performance, reliable, and energy-efficient storage solution. Its advanced features, such as NVMe 1.3 support, high endurance, and superior data reliability, make it an excellent choice for industrial applications, embedded systems, and other high-demand environments.
Product Description:
Feature | Description |
---|---|
Capacity | 20GB |
Form Factor | PCI Express® M.2 (2230/2242/2280, S4) |
Compliance | PCI Express (PCIe) Specification Revision 3.1 |
Interface | Gen3 x 4 Lanes |
Read Performance | Up to 1,780 MBytes/s |
Write Performance | Up to 867 MBytes/s |
Operating Temperature | -40 °C to 85 °C |
Power Consumption | Low, with multiple power states |
Data Reliability | < 1 non-recoverable error per 10¹⁶ bits |
Endurance (TBW) | Client ≥ 6,300 TBW @ 80GB capacity |
NAND Flash Technology | TLC 3D NAND Flash in pSLC mode |
MTBF | > 2,000,000 hours |
Connector | High-performance processor with integrated parallel flash interface engines |
ECC | LDPC Code ECC with up to 120 bit correction per 1 KByte page |
Installation Steps
- Power off your device and disconnect it from the power source.
- Open the device casing to access the M.2 slot.
- Insert the Swissbit M.2 PCIe SSD N2600 M2 Series 20 GB into the M.2 slot.
- Secure the SSD with the screw provided.
- Close the device casing and reconnect the power source.
- Power on the device and configure the SSD in your BIOS or operating system.
Where It Can Be Used
The Swissbit M.2 PCIe SSD N2600 M2 Series 20 GB is ideal for:
- Industrial machinery
- Embedded systems
- High-performance computing applications
- Rugged environments requiring reliable storage solutions
What is the price of the Swissbit M.2 PCIe SSD N2600 M2 Series 20GB In Bangladesh?
Discover a wide range of accessories and storage at unbeatable prices in Bangladesh with Crystal Vision Solutions. We offer Swissbit-branded SSDs, includingSwissbit M.2 PCIe SSD N2600 M2 Series 20GB, at the best prices in BD. To know the current price of this product please call us or visit our shop.
FAQ:
Q: What is the endurance of the Swissbit M.2 PCIe SSD N2600 M2 Series 20 GB?
A: The endurance is rated at Client ≥ 6,300 TBW at 80GB capacity.
Q: Can the Swissbit M.2 PCIe SSD N2600 M2 Series 20 GB operate in extreme temperatures?
A: Yes, it has an operating temperature range of -40 °C to 85 °C.
Q: What is the power consumption of this SSD?
A: The SSD has low power consumption with multiple power states (PS0, PS1, PS2, PS3, and PS4) and supports thermal throttling.
Q: Is the Swissbit M.2 PCIe SSD N2600 M2 Series 20 GB compliant with PCIe Specification Revision 3.1?
A: Yes, it is compliant with PCI Express (PCIe) Specification Revision 3.1.
Q: Does it support NVMe 1.3?
A: Yes, it supports NVMe 1.3 command sets.
